Brand new for 2020, the 18000 BTU - 19 SEER Suspended Ceiling INVERTER Ductless Mini Split air conditioner and Heat Pump by Thermocore provides both cooling & heating in areas up to 900 ft² large. Benefits of this series Include: I-Feel control, Anti-bacteria Filtration, intelligent Control Systems and comes fully charged with R410A. Includes a Digital LCD remote control, installation kit with 15 ft of copper piping+wire and Full 1/5 Year Warranty Package.

Home > Mini Splits > 1.5 Ton >

18000 BTU Ductless Air Conditioner

Air Conditioners - Split AC's, Portable AC's, Air Cooler Source
855-382-8110
Mini Split Air Conditioners
Search BY BTU Capacity:


Inverter Systems
Single-Zone
Dual-Zone
Tri-Zone
Quad-Zone
Quint-Zone (5)
Energy Star
Temperature Control: Portable A/C's, Window A/C's, Air Coolers, Ductless Splits,
Portable AC's >
Mini Wall Splits >
Ceiling Cassettes >
Suspended Ceiling >
Central AC's >
Window AC's >
Air Coolers >
Space Heaters >
Air Purification: IONIZERS, HEPA Filters, UV-TION
Ionizers >
HEPA >
UV/Tion >
Supplies >
Humidity Control: Humidifiers, Dehumidifiers
Humidifiers >
Dehumidifiers >

Accessories
12000 BTU Mini Split
System
Indoor Unit Remote Control Outdoor Unit warranty
 System Includes:
  • Indoor Unit - Suspended Ceiling Air Handler
  • Outdoor Unit - Compressor
  • Digital, Multi-function LCD Remote Control
  • Product Manuals
  • 15ft lineset/15ft wire included
  • Extend linesets & wire using dropdown menu
  • Washable Screen - Anti Bacteria Filter
  •

    18000 BTU SPLIT AC - Heat Pump: 19 Seer


    Price: $1288.45 Free Shipping
  • Select your choice of length for BTU:
  • Select to add wire
    Features back to the top
    Inverter Split
    Top Line Features:
  • 19 Seer - 8.6 HSPF - AHRI CERTIFIED
  • Suspended from ceiling or floor placement
  • Pre-Charged w/ Eco-friendly R410A Refrigerant
  • Ideal for Large Commercial Applications
  • Built in Drain Pump removes Moisture
  • Cross Flow Technology reduces noise output
  • Freon Leak Detection > Notification system
  • Low Ambient Temperature Operation (-13° F)
  • Restart IC: Settings restored Following Outage
  • Follow-Me Function tracks Remote Location
  • Follow-Me
    19 SEER ETL LISTED Toshiba Compressor 5 Year Air Conditioner Warranty R410A refrigerant
    Specifications back to the top
     Specs
    Remote Controls back to the top
    DC Inverter Mini Split AC Heat Pump WHAT IS DC INVERTER?

    DC Inverter Air Conditioners are the ultimate cooling technology of the HVAC field. They are called "DC inverter" because the alternative current (AC) is converted to Direct Current (DC) then, direct current inverted back to Alternative current with desired frequency. The current supplied through the wall outlet has fixed frequency which is 60 Hertz. Different frequencies supplied to the compressor will result in different running speeds of the compressor. Inverter control systems use Pulse Amplitude Modulation (PAM) that is the most advanced and energy efficient method of inverting the current. DC Inverter AC's bear special compressors that their speed could be changed by increasing or decreasing the frequency of the supplied power. Therefore, unlike conventional split Air Conditioners Pumps which cycle between on and off repeatedly, the DC Inverter control system will monitor the room temperature and adjust the compressor speed automatically.

    Conventional compressors turn on and off to maintain the room temperature at desired level. This will result compressor to draw tremendous energy each time it starts up. This will also reduce the life-span of the compressor and other components that are turning on and off. Once a conventional system is running, it runs at its maximum speed, consuming the maximum amount of energy in order to produce the maximum of cooling to maintain the desired temperature. The system will then cycle between on and off in an effort to maintain this temperature. When a DC Inverter compressor initially starts up, it runs with a higher speed to bring the room temperature to desired level rapidly, Once the set temperature is reached, it slows down and adjust its capacity just to counter the heat loss or heat gain of the building. Constant temperature is maintained.



    DC Inverter Energy Efficient Heating & Cooling Mini Splits
    Inverter Mini Split Air Conditioner Saves Money

    Inverter Mini Split Air Conditioners Are Energy Efficient & Save Money
    Install Kit back to the top
     Install Kit Contents:
  • 15 ft Flared Copper Tubing
  • 15 ft Pipe Insulation
  • 12 Ft Electrical Wire - INDOOR>OUTDOOR (16/4)
  • Drain Pipe (indoor)
  • Wall Bracket for Indoor Unit
  • Plastic Pipe Wrap
  •   Includes Install Kit
  • Installation and User Manual
  • Neoprene  Putty to Seal Holes
  • 8 Ft Electrical Wire - OUTDOOR>BOX (10/3)

  •   Install Kit
    Installation Overview back to the top
    BASIC OVERVIEW:  The indoor unit is hung like a picture frame approximately 6 - 8 feet above the floor usually on an exterior wall.  A 2-3 inch hole must be made behind the indoor unit in the exterior wall to run the refrigerant copper tubing, electrical wires and condensate drain to the outside unit. The indoor unit and outdoor unit are connected to each other by means of refrigerant copper tubing and electrical cables.  The condensing unit comes pre-charged with R410A Freon however, procedures such as conducting leak tests etc. are still important steps in ensuring proper functioning system.  Click for installation manual - Click for User Manual.  *Although installation may seem easy to some, certain tools and experience is necessary to complete setup of a mini split*  Click for Installation Tip.  It is highly advised a certified HVAC technician complete installation to be eligible for warranty.  See warranty details below > Installation Kit
    following_install
    Living Room Ductless Split Setup
    Available Accessories back to the top

    US   SHIPS TO TO BOTH UNITED STATES AND CANADIAN LOCATIONS!   Canadian
    Our Thermocore systems ship via RL Carriers or similar LTL freight service out of Oak Park, Michigan and are palletized onto a single skid.  Transit time is usually between 4 to 6 business days from payment receipt depending on where you are geographically located.  Please provide a contact phone# upon checkout (to be used for delivery purposes only).  SOMEBODY MUST BE ON SITE TO ACCEPT / SIGN FOR Order.  Failure to provide valid contact# will delay order.  System comes with Free shipping - this includes delivery to any location within the Continental United States. We will ship to Canadian locations but we need to quote separately - please contact our offices.  Additional freight for Canadian registries is usually around $150. (import and duties may apply).

      RL Carriers
    Remote Controls back to the top
    *5 Year Compressor - 1 Year on all other Parts*  Registration card will be sent with unit, this card should be completed by an HVAC technician (installer).  Installation of a mini split must be completed by a licensed HVAC (Heating, ventilating, & air conditioning) company to ensure any issues encountered in the future are not due to improper installation / workmanship.  Even though mini split setup is below the expertise requirements of central AC systems, these are not "plug-n-play" units that can be properly installed without certain tools any prior HVAC - electrical knowledge.   The installation includes electrical, gas, and refrigerant connections and generally regulated by a multiple sets of laws, codes and guidelines, at the federal, state and local levels. The failure to properly install HVAC equipment can raise personal safety and performance concerns. Warranty service - troubleshooting is provided through the contractor / installer and will be upheld as long as policies are observed.  Once a non-defective unit is installed by a HVAC company, chances of anything going wrong are very slim and almost all contractors will guarantee there workmanship and provide future service free of charge (installation warranty).  If it was determined that the unit is not functioning due to a defect and needs to be replaced, the part will be sent free of charge up to 1 year from date of purchase or 5 years for the compressor. If you receive a damaged or defective product, a replacement unit will be sent out Free of cost.  Damaged / Defective product will be picked up and a brand new exchange will be shipped out. Download Warranty Spreadsheet

    pdf files

    User Manual
    Installation
    Warranty
    Warranty
    Specs
    Specs
