18000 BTU Dual Zone Ductless Mini Split Air Conditioner

rThis Dual-Zone 18000 BTU Mini split Air Conditioneis a great cost efficient system for cooling TWO separate 9000 BTU zones for a total coverage area of 700 ft² (TWO 325 ft² areas). This package system comes complete with 2 digital remote controls, 16 foot installation Kit (Upgrade to 25 feet is available) and comes pre-charged with R-22 refrigerant. Compressor Warranted for 5 full years - 1 Year on Parts.

Home > Mini Splits > 1.5 Ton >

18000 BTU Dual-Zone AC: HEIL

855-382-8110

Home - About - SiteMap - Contact

Search BY BTU Capacity:

Portable AC's >
Mini Wall Splits >
Ceiling Cassettes >
Suspended Ceiling >
Central AC's >
Window AC's >
Air Coolers >
Space Heaters >

Ionizers >
HEPA >
UV/Tion >
Supplies >
Humidity Control: Humidifiers, Dehumidifiers

Humidifiers >
Dehumidifiers >

System Includes:

Indoor Unit - Air Handler

Outdoor Unit - Compressor

Digital, Multi-function LCD Remote Control

Installation Kit + Product Manuals

18000 BTU Dual-Zone Ductless AC
Price:	$

Top Line Features:

5 Year Compressor Warranty - 1 Year Parts Warranty

Pre-Charged with Eco-friendly R-410a Refrigerant

18,000 BTU's of Turbo Cooling : 9000 BTU x 2

Saves labor cost: fast coupling pipe for R410A & Power

Active carbon filter for clean air circulation

Automatic self-diagnosis system for easy maintenance

Multi function LCD-screen remotes for easy operation

Solves thermal shock problem as with conventional ACs

Enhanced Copper Coil - Wide Angle Air Spread

System Specifications:

Total Cooling Capacity:	18000 BTU's (cooling only)
Capacity Per Air Handler:	9000 BTU's (x2)
Airflow Of Indoor Fans:	350 CFM (x2)
Moisture Removal:	2.6 Pints/Hour (x2)
Indoor Noise Level:	45-55 dB(A) (low-high)
Outdoor Noise Level:	74 dB(A)
Fan Speed Settings:	3 Fan Speed Settings
Filter:	Washable
Compressor Type:	Rotary
Compressor Brand:	HEIL
Refrigerant:	R-22
Factory Pre-charge:	2.7 lbs (x2)
Indoor Unit Dimensions: (x2)	10.3"H x 32.1"W x 7.3"D - 19 lbs.
Outdoor Unit Dimensions:	50.4"H x 35.5"W x 12.6"D - 136 lbs.

Electrical Info:

Power Supply (VAC):	1, 115V ~ 60Hz
SEER: (Energy Efficiency)	13 SEER
Minimum Circuit Ampacity:	19.8 Amps
Max. Over Current Protective Device:	25 Amps
Compressor Rated Load:	7.2 Amps
Locked Rotor Amps:	42 Amps
Fan Motor Amps:	1 Amps

Piping - Kit Info:

Connection Method:	Flare
Liquid Line Connection Size:	1/4" (x2)
Vapor Line Connection Size:	1/2" (x2)
Max Pipe Length:	50 Feet
Max Elevation:	30 Feet

Install Kit Contents:

16 Feet Flared Refrigeration Tubing
Installation Plate
Clip Ancors w/ Mounting Screws
Drain Elbow (outdoor)
Wall Cross pipe
Drain Seal
Remote w/ sleep timer
Remote Wall Bracket

BASIC OVERVIEW: The indoor unit is hung like a picture frame approximately 6 - 8 feet above the floor usually on an exterior wall. A 2-3 inch hole must be made behind the indoor unit in the exterior wall to run the refrigerant copper tubing, electrical wires and the condensate drain to the outside unit. The indoor unit and outdoor unit are connected to each other by means of refrigerant copper tubing and electrical cables. See Installation Manual The condensing unit comes pre-charged with R410A Freon however, the lines still need to be vacuumed to evacuate the excess Nitrogen prior to the final coupling for operation. *Although the installation may seem easy to some, certain tools and experience is necessary to complete installation of a mini split* See User Manual . It is highly advised a certified HVAC technician conduct / complete installation to be eligible for warranty. (See warranty details below > )

Multi Zone Mini Split Air Conditioners / Heat Pumps Provide Flexible Layout Options

This Mini Split unit ships via FEDEX FREIGHT (on truck) and are divided between 3 parcels per system (install kit - condenser - air handler). These units ship out of So. Florida and are in transit with 1-2 business days of payment receipt. Depending on where you are geographically located, transit time is usually between 4 and 7 business days. Please provide a contact phone# upon checkout where recipient of order can be reached at. SOMEBODY MUST BE ON SITE TO ACCEPT / SIGN FOR PARCEL(S). Only ships to the lower 48 Contiguous United States.

Click to Download Warranty Details: A mini split system must be installed by a licensed HVAC (Heating, ventilating, & air conditioning) company to ensure any issues encountered in the future are not due to improper installation / workmanship. Even though mini split setup is below the expertise requirements of central AC systems, these are not "plug-n-play" units that can be properly installed without certain tools any prior HVAC - electrical knowledge. The installation includes electrical, gas, and refrigerant connections and generally regulated by a multiple sets of laws, codes and guidelines, at the federal, state and local levels. The failure to properly install HVAC equipment can raise personal safety and performance concerns. Warranty service - troubleshooting is provided through the contractor / installer and will be upheld as long as policies within Warranty spreadsheet are observed. Once a non-defective unit is installed by a HVAC company, chances of anything going wrong are very slim and almost all contractors will guarantee there workmanship and provide future service free of charge (installation warranty). If it was determined that the unit is not functioning due to a defect and needs to be replaced, the part will be sent free of charge. If you receive a damaged or defective product, a replacement unit will be sent out Free of cost. Damaged/Defective product will be picked up and a brand new exchange will be shipped out.
