Aircon ALMCI4H4R36: Enjoy full season comfort during the summer or winter with this 3 TON Inverter Mini Split with 36000 BTU Heat Pump. With a 18 SEER rating coupled with advanced DC Inverter technology provides the benefits of low operation temperatures, rapid cooling / heating as well as maximum energy efficient operation. Comes fully charged with eco-friendly R410A and includes complete 5 Year Compressor - 2 Year Part Warranty Package.

Home > Mini Splits > 36000 BTU >

3 Ton AC - Heat Pump

Air Conditioners - Split AC's, Portable AC's, Air Cooler Source
407-965-2133
Mini Split Air Conditioners
Search BY BTU Capacity:


Inverter Systems
Single-Zone
Dual-Zone
Tri-Zone
Quad-Zone
Quint-Zone (5)
Energy Star
Temperature Control: Portable A/C's, Window A/C's, Air Coolers, Ductless Splits,
Portable AC's >
Mini Wall Splits >
Ceiling Cassettes >
Suspended Ceiling >
Central AC's >
Window AC's >
Air Coolers >
Space Heaters >
Air Purification: IONIZERS, HEPA Filters, UV-TION
Ionizers >
HEPA >
UV/Tion >
Supplies >
Humidity Control: Humidifiers, Dehumidifiers
Humidifiers >
Dehumidifiers >

Accessories
36000 BTU inverter Split
system
Indoor Unit Remote Control Outdoor Unit Installation Kit
 System Includes:
  • 36,000 BTU Cooling Capacity
  • 36,000 BTU Heating Capacity
  • INVERTER TECHNOLOGY - 18 SEER / 9 HSPF
  • Digital Multi-function LCD Remote Control
  • Product & Installation Manuals
  •

    3 TON Inverter AC - Heat : 18 SEER

    Price: $2162.45   Free Shipping
    Features back to the top
    Mini Split
    Top Line Features:
  • 18 SEER - 9.0 HSPF - AHRI CERTIFIED
  • Pre-Charged w/ Eco-friendly R410A Refrigerant
  • Dry-Mode removes moisture w/o affecting temp
  • Cross Flow Technology reduces noise output
  • Easy Maintence - Panel Removes for Access
  • Low Ambient Temp. Operation (0 - 109 F)
  • Two-direction Air vane Evenly Distributes Air
  • Restart IC: Settings restored Following Outage
  • 2 Year Part - 5 Year Compressor Warranty  >>>
  • ** Installation Kit Sold Seperately: Available in 15-75ft Lengths.
    Contact us
    for customized package or Click here to Purchase.
    Mini Split Features
    Specifications back to the top
    Parameter Unit Value
    Model / ALMCI4H4R36 / ALMEM4H4R36
    Power Supply Rated Voltage V 208/230
    Rated Frequency Hz 60
    Phases / 1
    Cooling Capacity (Min~Max) BTU/h 33600(7400~36000)
    Heating Capacity (Min~Max) BTU/h 34600(15000~36000)
    Cooling Power Input W 4100(450~4300)
    Heating Power Input W 3800(560~4300)
    Cooling Current Input A 17
    Heating Current Input A 16.5
    Rated Input W 4300
    Rated Current A 20.0
    Air Flow Volume (SH/H/M/L/SL) CFM 736/647/-/530/-/412/-
    m3/h 1250/1100/-/900/-/700/-
    Dehumidifying Volume Pint/h 7.40
    L/h 3.50
    EER BTU/Wh 8.20
    COP BTU/Wh 9.11
    SEER / 18
    HSPF / 9.0
    Application Area ft2 495-1500
    Indoor Unit Indoor Unit Model / ALMEM4H4R36
    Fan Type / Cross-Flow
    Cooling Speed (SH/H/M/S/SL) r/min 1400/1250/1000/800
    Heating Speed (SH/H/M/L/SL) r/min 1400/1250/1050/850
    Fan Motor Power Output W 70
    Fan Motor RLA A 0.40
    Evaporator Form Aluminum Fin-copper tube
    Evaporator Row-fin Gap inch 2-0.055
    Evaporator Coil Length (LXDXW) inch /
    Swing Motor Model / MP24BA
    Swing Motor Power Output W 1.5
    Fuse Current A 3.15
    Sound Pressure Level (SH/H/M/L/SL) dB(A) 54/49/44/37
    Sound Power Level (SH/H/M/L/SL) dB(A) 64/59/54/47
    Dimension (WXHXD) inch 53.15 X 12.835 X 9.961
    Dimension of Carton Box (LXWXH) inch 56.614 X 16.457 X 13.858
    Dimension of Package (LXWXH) inch 56.732 X16.575 X 14.449
    Net Weight lb 41.9
    Gross Weight lb 51.8
    Outdoor Unit Outdoor Unit Model / ALMCI4H4R36
    Compressor Manufacturer / MITSUBISHI ELECTRIC COMPRESSOR CO.
    Compressor Model / TNB306FPGMC
    Compressor Oil / FV50S
    Compressor Type / Rotary
    L.R.A. A 67
    Compressor RLA A 13.5
    Compressor Power Input W 3010
    Compressor Overload Protector / CS01F272H01
    Throttling Method / Electronic Expansion Valve
    Set Temperature Range °F 61~86
    °C 16~30
    Ambient Temperature (Cooling) °F 0~109.0
    °C (-18.0)~43.0
    Ambient Temperature (Heating) °F (-4.0)~75.0
    °C (-20.0)~24.0
    Condenser Form / Aluminum fin-copper tube
    Condenser Rows-fin Gap inch 2-0.055
    Fan Type / Axial Flow
    Defrosting Method / Automatic Defrosting
    Climate Type / T1
    Moisture Protection / IP24
    Max Operating Pressure for the Discharge Side MPa 4.3
    PSI 623
    Max Operating Pressure for the Pressure Side MPa 2.5
    PSI 362
    Sound Pressure Level (H/M/L) dB(A) 65/-/-
    Sound Power Level dB(A) 75/-/-
    Dimension (WXHXD) inch 38.6 X 31.1 X 16.8
    Dimension of Carton Box (L/W/H) inch 42.5 X 19.1 X 33.1
    Dimension of Package (L/W/H) inch 42.6 X 19.2 X 33.7
    Net Weight lb 161.0
    Gross Weight lb 172.0
    Refrigerant / R410A
    Refrigerant Charge oz 84.7
    Electric Breaker -Fuse Size A 2-Pole - 30Amps
    Connection Pipe Length ft 24.6
    Gas Additional Charge oz/ft 0.5
    Outer Diameter Liquid Pipe in Φ1/4
    Outer Diameter Gas Pipe in Φ5/8
    Max Distance Height ft 32.8
    Max Distance Length ft 98.4
    ARI Certified 16 SEER Cooling & Heating R410A refrigerant Warranty
    Remote Controls back to the top
    inside
    WHAT IS DC INVERTER?

    DC Inverter Air Conditioners are the ultimate cooling and heating technology of the HVAC field.  They are called "DC inverter" because the alternative current (AC) is converted to Direct Current (DC) then, direct current inverted back to Alternative current with desired frequency. As known, the current supplied through the wall outlet has fixed frequency which is 60 Hertz. Different frequencies supplied to the compressor will result different running speeds of the compressor. Inverter control systems use Pulse Amplitude Modulation (PAM) that is the most advanced and energy efficient method of inverting the current.  DC Inverter air conditioners bear special compressors that their speed could be changed by increasing or decreasing the frequency of the supplied power.  Therefore, unlike conventional split Air Conditioners/Heat Pumps which cycle between on and off repeatedly, the DC Inverter control system will monitor the room temperature and adjust the compressor speed automatically.

    Conventional compressors turn on and off to maintain the room temperature at desired level.  This will result compressor to draw tremendous energy each time it starts up. This will also reduce the life-span of the compressor and other components that are turning on and off.  Once a conventional system is running, it runs at its maximum speed, consuming the maximum amount of energy in order to produce the maximum of cooling or heating to maintain the desired temperature.  The system will then cycle between on and off in an effort to maintain this temperature. When a DC Inverter compressor initially starts up, it runs with a higher speed to bring the room temperature to desired level rapidly. Once the set temperature is reached, it slows down and adjust its capacity to counter the heat loss or heat gain of the building. By this way it will maintain a constant temperature.

    Inverter Split Benefits
    INVERTER GRAPH
    Installation Overview back to the top
    BASIC OVERVIEW:  The indoor unit is hung like a picture frame approximately 6 - 8 feet above the floor usually on an exterior wall.  A 2-3 inch hole must be made behind the indoor unit in the exterior wall to run the refrigerant copper tubing, electrical wires and the condensate drain to the outside unit. The indoor unit and outdoor unit are connected to each other by means of refrigerant copper tubing and electrical cables.  The condensing unit comes pre-charged with Freon however, the lines still need to be vacuumed to evacuate the excess Nitrogen prior to the final coupling for operation.  Click to Download Installation Manual. *Although the installation may seem easy to some, certain tools and experience is necessary to complete installation of a mini split*  See Installation Tip.  A certified HVAC technician must conduct / complete the installation to be eligible for the warranty.  (See warranty details below > ) Installation Kit
    Installation Diagram
    Living Room Ductless Split Setup   How will look After Installation
    Remote Controls back to the top
    *5 Year Compressor - 1 Year on all other Parts*  Registration card will be sent with unit, this card should be completed by an HVAC technician (installer).  Installation of a mini split must be completed by a licensed HVAC (Heating, ventilating, & air conditioning) company to ensure any issues encountered in the future are not due to improper installation / workmanship.  Even though mini split setup is below the expertise requirements of central AC systems, these are not "plug-n-play" units that can be properly installed without certain tools any prior HVAC - electrical knowledge.   The installation includes electrical, gas, and refrigerant connections and generally regulated by a multiple sets of laws, codes and guidelines, at the federal, state and local levels. The failure to properly install HVAC equipment can raise personal safety and performance concerns. Warranty service - troubleshooting is provided through the contractor / installer and will be upheld as long as policies are observed.  Once a non-defective unit is installed by a HVAC company, chances of anything going wrong are very slim and almost all contractors will guarantee there workmanship and provide future service free of charge (installation warranty).  If it was determined that the unit is not functioning due to a defect and needs to be replaced, the part will be sent free of charge up to 1 year from date of purchase or 5 years for the compressor. If you receive a damaged or defective product, a replacement unit will be sent out Free of cost.  Damaged / Defective product will be picked up and brand new exchange will be shipped out.  Download Manual - Warranty Polices >
    Available Accessories back to the top


    US   SHIPS TO  TO BOTH UNITED STATES AND CANADIAN LOCATIONS!   Canadian
    Our Thermocore  systems ship via RL Carriers or similar LTL freight service out of Pompano Beach, Fl and are palletized onto a single skid.  Transit time is usually between 4 to 6 business days from payment receipt depending on where you are geographically located.  Please provide a contact phone# upon checkout (to be used for delivery purposes only).  SOMEBODY MUST BE ON SITE TO ACCEPT / SIGN FOR Order.  Failure to provide valid contact# will delay order.  System comes with Free shipping - this includes delivery to any location within the Continental United States. We will ship to Canadian locations  but we need to quote separately - please contact our offices.  Additional freight for Canadian registries is usually around $150. (import and duties may apply).
