Klimaire KSWG024-H213 Mini Split Air Conditioner

The Klimaire KSWG024-H213 2 Ton Ductless Mini split air conditioner with heat pump is a great cost efficient system for cooling areas over 1000 ft². Like any A/C you need to know how many BTUs are needed for the area you are trying to cool - heat. A mini split air conditioner is very quiet and efficient, but it is more expensive than a window or portable system. Since they are ductless, the mini split AC/Heaters avoid the energy losses associated with the ductwork of central forced systems

Home > Mini Splits > 2 Ton >

24000 BTU AC - Heat Pump: KSWG

407-965-2133

Home - About - SiteMap - Contact

Search BY BTU Capacity:

Portable AC's >
Mini Wall Splits >
Ceiling Cassettes >
Central AC's >
Window AC's >
Air Coolers >
Space Heaters >

Ionizers >
HEPA >
UV/Tion >
Supplies >
Humidity Control: Humidifiers, Dehumidifiers

Humidifiers >
Dehumidifiers >

System Includes:

Indoor Unit - Air Handler

Outdoor Unit - Compressor

Digital, Multi-function LCD Remote Control

Installation Kit + Product Manuals

Pre-Heating Function & Super Filter Screen

24000 BTU MINI SPLIT AC - Heat Pump
Price:	$1389.45

System Specifications:

Capacity Heating / Cooling:	24,000 BTU's
Airflow Volume:	766 (CFM)
Moisture Removal:	1.9 Liters / hour
Thermostat Range:	64° F - 88° F
Inside Noise Output:	46 – 51 dB(A)
Outside Noise Output:	65 dB(A)
Fan Speed Settings:	(3) + Automatic
Filters:	Washable Filter Screen
Compressor Type:	Rotary
Compressor Brand:	Toshiba
Refrigerant / Charge:	prec-R410a / 2500 grams
Dimensions - Indoor Unit:	48.6" W x 9.8" D x 12.8" H
Weight - Indoor Unit:	44 Pounds
Dimensions - Outdoor Unit:	36" W x 13" D x 32.9" H
Weight - Outdoor Unit:	143 Pounds

Electrical Info:

Power Supply (VAC):	230/208 - 60Hz
HSPF (Btu/w.h):	7.7
SEER: (Energy Efficiency)	13
Power Consuption:	1980 Watts
Running Load Current:	10.5 Amps
Locked Rotor Current:	48.9 Amps
Starting Current:	34.8 Amps

Piping - Kit Info:

Connection Method:	Nut
Pipe Size (Liquid Side - Gas Side):	3/8" - 5/8"
Tubing / Piping Included:	15 Feet
Drain Connection Size:	5/8"
Gas Charging Weight:	2500 Grams

Install Kit Contents:

16 Feet Refrigeration Tubing
Installation Plate
8 Clip Ancors w/ Mounting Screws
Drain Elbow (outdoor)
Wall Cross pipe
Drain Seal
Remote w/ sleep timer
Remote Wall Bracket

BASIC OVERVIEW: The indoor unit is hung like a picture frame approximately 6 - 8 feet above the floor usually on an exterior wall. A 2-3 inch hole must be made behind the indoor unit in the exterior wall to run the refrigerant copper tubing, electrical wires and the condensate drain to the outside unit. The indoor unit and outdoor unit are connected to each other by means of refrigerant copper tubing and electrical cables. The condensing unit comes pre-charged with R410A Freon however, the lines still need to be vacuumed to evacuate the excess Nitrogen prior to the final coupling for operation. *Although the installation may seem easy to some, certain tools and experience is necessary to complete installation of a mini split* See installation Manual. It is highly advised a certified HVAC technician conduct / complete installation to be eligible for warranty. (See warranty details below > )

This Mini Split unit ships via FEDEX FREIGHT (on truck) and are divided between 3 parcels per system (install kit - condenser - air handler). These units ship out of South Florida and are in transit with 1-2 business days from payment receipt. Depending on where you are geographically located, transit time is usually between 4 and 7 business days. Please provide a contact phone# upon checkout where recipient of order can be reached at. SOMEBODY MUST BE ON SITE TO ACCEPT / SIGN FOR Order. Only ships to the lower 48 Contiguous United States.

Click to Download Warranty Details: A mini split system must be installed by a licensed HVAC (Heating, ventilating, & air conditioning) company to ensure any issues encountered in the future are not due to improper installation / workmanship. Even though mini split setup is below the expertise requirements of central AC systems, these are not "plug-n-play" units that can be properly installed without certain tools any prior HVAC - electrical knowledge. The installation includes electrical, gas, and refrigerant connections and generally regulated by a multiple sets of laws, codes and guidelines, at the federal, state and local levels. The failure to properly install HVAC equipment can raise personal safety and performance concerns. Warranty service - troubleshooting is provided through the contractor / installer and will be upheld as long as policies within Warranty spreadsheet are observed. Once a non-defective unit is installed by a HVAC company, chances of anything going wrong are very slim and almost all contractors will guarantee there workmanship and provide future service free of charge (installation warranty). If it was determined that the unit is not functioning due to a defect and needs to be replaced, the part will be sent free of charge. If you receive a damaged or defective product, a replacement unit will be sent out Free of cost. Damaged/Defective product will be picked up and a brand new exchange will be shipped out.
